A Detail Sheet Metal Gauge Chart by Regentsteel
If youre within the metalworking industry, whether youre a producer, fabricator, or builder, you know choosing the correct thickness of sheet metal is significant. Thats where a sheet metal gauge chart comes into play.
This chart converts gauge numbers into real thickness (in mm or inches), making it simpler to choose the right fabric for your venture.
What is Sheet Metal Gauge?
The gauge of a sheet metal alludes to its thickness. Its a standardized estimation, the lower the gauge, the thicker the metal, and the higher the gauge, the more slender it is.
For illustration:
10-gauge steel is thick, approximately 3.42 mm. wherea
20 gauge is more slender, almost 0.91 mm.
Here are the list of commonly utilized thickness values (in mm) for sheet metal:
Steel (Mild or Carbon)
10 gauge 3.42 mm
14 gauge 1.9 mm
16 gauge 1.52 mm
18 gauge 1.21 mm
20 gauge 0.91 mm
Stainless Steel
10 gauge 3.57 mm
14 gauge 1.98 mm
16 gauge 1.59 mm
18 gauge 1.27 mm
20 gauge 0.95 mm
Applications Based on Gauge Thickness:
1014 gauge: Basic components, overwhelming brackets, car outlines, agricultural equipment.
1620 gauge: Car body boards, material, ductwork, furniture, machines.
Higher gauge (over 20): Light casings, walled in areas, decorative components, jewelry.
Why Sheet Metal Gauge Chart is So Important?
Ensuring you select the right thickness for your application.
Giving uniform wording over engineers, providers, and fabricators.
Making a difference you maintain a strategic distance from under-engineering or over-engineering.
Making estimating, sourcing, and fabric acquiring more exact.
Always refer to a certified chart of sheet metal gauge for your fabric of choice.
Approve thickness physically in case youre uncertain, it maintains a strategic distance from expensive mistakes afterward.
